Moonray Compact
A flexible and
adaptable
solution, with no
limits in surgery
performances.
created having taken into
consideration small spaces and
frequent handling inside hospitals
DETECTORS FOR ALL NEEDS
Wide and free choice between the latest
powerful Active CMOS flat X-Ray detector
technology and the classic reliability of
the image intensification technology.
1K x1K DIGITAL VIDEO CHAIN
Perfect integrations of 1kx1k matrix
quality and digital quality of 19” TFT color
monitors 1280x1024 pixel resolution
with high brightness and contrast
DIFFERENT POWER GENERATORS
The best power range to cover any
type of performance needed
INTEGRATEDLIQUID
COOLINGSYSTEMS
ilX and ilXPlUS are our liquid cooling
systems completely separated from the
device’s main electrical wiring, specifically
designed for the Moonray Systems’ range.
ROTATINGANODE
Simad systems are equipped with
x-ray tubes with rotating anodes, at
high speed, high thermal dissipation
and reduced focal spot.
Focal spot 0.3 mm in fluoroscopy •
Focal spot 0.6 mm in radiography
HIGHDISSIPATIONSYSTEM™
Simad x-ray medical technology
has designed, developed and
created hdS™ which represents a
new approach to improve heating
dissipation due to x-ray exposures.
components involved are made of very
conductive materials (al) and all coupling
interfaces provide low thermal impedance.
heating runs through a dedicated
dissipation channel, and exchange
surface is appreciably increased.
25%
*
increase in
working time
25%
*
reduction
in cooling time
A LIGHTEST EXPERIENCE OF HANDLING
Precise counterbalancing of the “c” and improved
design of the base frame, make Moonray Systems
exceptionally lightweight during the positioning
ONE HANDLE FOR
ALL DIRECTIONS
Moonray Systems positioning is precise
and very smooth. rear wheel orientation
allows movement in any direction.
The unique ergonomic steering handle
allows parallel movement for easy
positioning alongside operating table
ALL OUR IMAGE QUALITY IS
CARRIED BY THEM, THAT’S
wHYwHEELS ARE NO LESS
IMPORTANT FOR US
Moonray Systems’ wheels are entirely
designed and manufactured by
Simad through a specific study to get
the best handling performance.
Stationary braking system is easy
and comfortable to reach.
EXTREMELY SMOOTH AND
EASY-CLEANING SURFACE
aspecial coating technique based on
the automotive industry processes,
gives to our products’ surfaces an
extraordinary durability, and thanks
to its mirrorlike finishing an accurate
and easy cleaning is guaranted
TwO CONNECTORS’ CABLE
Facilitates system handling and moving.
easy to replace in case of damage.
LOwDOSE CONTROL™
adigital patented system for superior
image quality using 7 times less
dosage to patients and operators.
AUTOMATIC DOSE REPORT™
Built-in adr™ system automatically measures
the dose report of each procedure.
dose reports readily available to be stored
into the patient’s file or printed.
FULL DIGITAL SYSTEM™
nowadays medicine requires ever-growing solutions that
communicate without limits and this is possible only through
the use of digital solutions. SiMadhas developed and made
real an open system which can remain updated in time.
DICOM software package •
Digital film printer •
High Capacity DVD/CD •
USB connection •
Remote Training and Assistance •
TCP/IP Network •
Memory storage capacity over 250.000 images •
DICOM | BMP | AVI | JPG
export your best imaging procedures in the most common
files format for conference reports, training and congresses.
DICOM
®
SOFTwARE PACKAGE
Moonray Systems can be upgrated
whenever needed thanks to
the possibility to install dicom
®
options on the workstation.
Printing •
Storage •
Work List •
Master Kit •
Query & Retrieve •
DICOM •
®
DAP
PREVIEw wITHOUT RADIOLOGICAL EXPOSURE
Moonray Systems software allows to omit all exposures which are
not strictly aimed to image acquisition for diagnostic purposes.
Iris collimator preview
The collimator’s opening and closing span can be set directly
on the monitor’s image by keeping a dynamic digital icon as a
landmark, the collimator can be positioned without x-ray exposure.
Preview of semitransparent compensator.
Through the digital icons available on the image monitor,
the user can open and close the semitransparent
compensators and rotate them clockwise and anti-clockwise
to the desired position. Without x-ray exposure.
Image rotation
Image rotation, which is finalized to align radiological
standards, can be seen in digital modality without x-ray
exposure. asimple icon and the digital preview allows
for the quick and precise orientation of the image on the
monitor. also vertical and horizontal reversals of image
are obtained digitally, with no need of x-ray exposure.
STATLAB™
Analysis and study of DAP Data
DATA DOwNLOAD
you can download daP data stored on
your Moonray System into an external
workstation, and then study data under
physics-mathematic points of view.
data downloading can be done from
whatever Moonray System and this
allows a detailed analysis of the
equipment functions and functionalities.
PROCESSING
The software allows the analysis
of daP data, exposure duration,
voltage and current in relation to:
Patient •
Type of procedure •
reference unit •
considering these variables,
it is possible to calculate total
amount, average and variance
ILXPLUS is our brand-new
hardware option* to have an
integrated liquid cooling system
at active high dissipation.
it has been designed and developed to
ensure long time xray emissions that often
occur in interventional radiology, such
as vascular applications in particular.
We achieved this technical feature
keeping in mind to have it into an
extremely contained dimension. The
monobloc size remains therefore perfectly
compatible with typical operating tables
used in the orand X-ray room.
The great technological advantage
of ilXPlUS is apllicable on the whole
range of our Moonray Systems. no
matter which model you choose
